Used Eurotech B465 SY2 CNC Lathe – 2013

Eurotech B465 SY2 CNC Lathe – 2013

SKU 11176

Make/Model Eurotech B465 SY2

Year 2013

Condition Used - Good

Video On Request

Out of stock

SKU:	11176
Make/Model:	Eurotech B465 SY2
Year:	2013
Condition:	Used – Good
Video:	On Request

SKU: 11176

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	Eurotech
Model No.:	B465 SY2
Year of Manufacture:	2013
Condition:	Used – Good
Machine Type:	Multi-Axis CNC Turning Center / Swiss-Type Lathe
CNC Control:	Fanuc Series 31i-B CNC Control

Equipped With:
Fanuc Series 31i-B CNC Control
Dual Spindle Configuration
Dual Y-Axis (Y1 / Y2)
Live Tooling System
Guide Bushing System
Automatic Bar Feeder Interface
Parts Catcher
Chip Conveyor
Coolant System
Automatic Lubrication System
Fully Enclosed Splash Guard
Work Light

Capacity:
Maximum Bar Capacity: 2.56″ (65 mm)
Maximum Turning Diameter: 65 mm
Maximum Turning Length (Guide Bushing): Approx. 150 mm
Maximum Turning Length (Without Guide Bushing): Approx. 165 mm

Travel:
X1 Axis Travel: 220 mm
Y1 Axis Travel: ±50 mm
Z1 Axis Travel: 320 mm
X2 Axis Travel: 220 mm
Y2 Axis Travel: ±50 mm
Z2 Axis Travel: 320 mm

Main Spindle:
Spindle Speed: Up to 4,500 RPM
Spindle Motor Power: Approx. 18.5 kW (25 HP)
Spindle Bore: 65 mm
Spindle Nose: A2-6

Sub Spindle:
Spindle Speed: Up to 6,000 RPM
Motor Power: Approx. 7.5 kW (10 HP)
Sub-Spindle Bore: Approx. 43 mm

Live Tooling:
Live Tool Speed: Up to 6,000 RPM
Live Tool Motor Power: Approx. 5.5 kW
Milling / Drilling / Tapping Capability

Feedrates:
Rapid Traverse: Approx. 30 m/min

Electrical:
Voltage: 400V
Phase: 3-Phase
Current: 75 A
Frequency: 60 Hz

General:
Machine Weight: 7,000 kg (15,432 lbs)
Heavy-duty Swiss-type machine base for high precision machining

Features:
Dual Y-axis multi-axis machining capability
Main and sub-spindle for complete part machining
Live tooling for milling, drilling, and tapping operations
Fanuc 31i-B control for advanced multi-axis programming
High-precision Swiss-type turning technology
Designed for complex small-to-medium precision parts
Ideal for medical, aerospace, electronics, and precision manufacturing industries

Categories	CNC Multi Axis Machining Center
Make	Eurotech
Model	B465 SY2

Payment Terms

A booking deposit secures the machine, with the remaining balance due prior to loading or shipment. We accept bank transfer, wire transfer, and approved payment methods.
