FANUC Oi Mate-TC CNC control, Fanuc AC drives and servo motors.
Coolant system w/magnetic separator & paper filter (60L/min, 140L)
Hydraulics, coolant and lubrication systems are separated from machine to eliminate vibration and dissipate heat
The design of the tailstock is both rigid and robust. Housed in a cast body, the hardened nitralloy steel sleeve is designed to carry a MT4 center
The One V and one flat hand-scraped guideways are Turcite coated and incorporated with an automatic lubrication system, precision ballscrew, AC servo motor and a 0.000004″ linear
feedback system to ensure smooth movement of the wheelhead for superior positioning accuracy and repeatability
Z-axis positioning accuracy and repeatability is assured with an AC servo motor and high precision, pre-tensioned ballscrews.
A swiveling table dial indicator enables rapid cylindricity corrections and taper grinding applications.
Full enclosure splash guard w/oil & mist separator
Heavily ribbed box-type base is made of Meehanite castings, providing excellent rigidity to ensure machine stability.
