All specifications are approximations and are subject to verification.
-
Hardinge Conquest CS-51 Equipped With:
- Fanuc OT-C CNC Control
- 12-Station Turret
- 8″ 3 Jaw Hydraulic Chuck or Collet Chuck (Option)
- Hydraulic Postioning Tailstock
- Chip Pan and Chip Conveyor
- Coolant System
- Automatic Lubrication system
- Foot Operated Control for Chuck
-
Hardinge Conquest CS-51 Specifications:
- Max Turning Diameter: 10.63″
- Max Turning Length: 19.68″
- Max Bar Capacity: 2.05″
- Swing Over Slide: 15.78″
- Swing Over Bed: 21.65″
- Distance Between Centers: 24.29″
-
Travel:
- X Axis Travel: 6.75″
- Z Axis Travel: 22.65″
- Rapid Traverse X Axis: 630 IPM
- Rapid Traverse Z Axis: 787 IPM
-
Spindle:
- Spindle Nose: A2-6
- Spindle Bore: 2.05″
- Spindle Speed: 4200 RPM
- Spindle Motor: 20 HP
-
Turret:
- Turret Capacity: 12 Stations
- Turret Index Time: 0.5 Second
-
Tailstock:
- Tailstock Body Travel: 19.0″
- Tailstock Quill Dia.: 3.54″
- Tailstock Taper: MT-4
-
General:
- Power Source: AC 220 V, Three Phase, 60 Hz
- Power Requirement: 68 Amps
- Overall Dimensions: 110″ x 68″ x 80″ High
- Overall Dimensions: 140″ x 68″ x 80″ High with Chip Conveyor
- Weight : 15000 lbs Approx.
