*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Mazak |
| Model: | QTS 350 |
| Year: | 2013 |
| Condition: | Used – Good |
| Machine Type: | CNC Turning Center |
| Country of Origin: | Japan |
| Features: |
|---|
- High-Rigidity Slant Bed CNC Lathe
- Powerful Built-In Spindle
- Servo-Driven Turret
- Rigid Tapping Capability
- Thermally Stable Machine Design
- Automatic Central Lubrication System
- Fully Enclosed Machining Area
- Heavy-Duty Chuck & Hydraulic Clamping
|
| Travels: |
|---|
- X-Axis Travel: 12.6″
- Z-Axis Travel: 41.0″
|
| Capacity: |
|---|
- Chuck Size: 15″
- Chuck Manufacturer: Kitagawa
- Chuck Model: B-15
- Max Turning Diameter: 16.5″
- Max Turning Length: 40.9″
- Bar Capacity: 4.0″
|
| Spindle: |
|---|
- Spindle Nose: A2-8
- Spindle Speed: 2,500 RPM
- Spindle Motor: 40 HP
- High-Torque Built-In Spindle
|
| Feedrates & Dynamics: |
|---|
- Rapid Traverse (X / Z): 945 IPM
- High-Torque Servo Drives
- Precision Ground Ballscrews
|
| Turret: |
|---|
- Turret Type: Servo-Driven Turret
- Tool Stations: 12 Stations
- Tool Size: 1.0″ Square / Ø2.0″ Boring
|
| Coolant System: |
|---|
- Flood Coolant System
- Coolant Tank Capacity: Approx. 120 Gallons
- Coolant Gun
|
| Chip Management: |
|---|
- Hinged Belt Chip Conveyor
- Fully Enclosed Chip Guarding
|
| CNC Control: |
|---|
- Mazatrol CNC Control
- Color LCD Display
- Conversational & EIA/ISO Programming
- Ethernet & USB Connectivity
|
| Electrical & General: |
|---|
- Power Supply: AC 208V / 3-Phase / 50–60 Hz
- Rated Capacity: 38 kVA
- Largest Motor: 40 HP
- SCCR: 50 kA
- Machine Weight: Approx. 15,750 lbs
|
