All specifications are approximations and are subject to verification.
-
Equipped With:
- MF-T6 (Fanuc 16T) CNC Control
- 12 Position Turret W/ 6 Live Stations
- C Axis
- Kitagawa B206 6.5″ Hydraulic Chuck
- Tool Presetter
- 2 Step gear spindle for powerful torque
- Hydraulic Tailstock with Power Quill
- Foot Switch
- Chip Pan
- Coolant System
- Live Tool Holders
-
Specifications:
- Capacity:
- Max Turning Diameter: 9.06″
- Max Turning Length: 20.7″
- Max Bar Capacity: 1.65″
- Swing Over Slide: 11.8″
- Swing Over Bed: 17.7″
- Distance Between Centers: 22.6″
-
Travel:
- X Axis Travel: 5.3″
- Z Axis Travel: 22.2″
- C Axis : 0.001
- Rapid Traverse X Axis: 790 IPM
- Rapid Traverse Z Axis: 945 IPM
-
Spindle:
- Spindle Nose: A2-5
- Spindle Bore: 2.1″
- Spindle Speed: 6000 RPM
- Spindle Motor: 20 HP
-
Turret:
- Turret Capacity: 12 Stations /6 Live
- Turret Index Time: 1 Second
- Live Tool Speed: 120 – 3000 RPM
-
Tailstock:
- Tailstock Body Travel: 19.3″
- Tailstock Quill Dia.: 4.33″
- Tailstock Quill Stroke: 3.93″
- Tailstock Taper: MT-4
-
General:
- Power Source: AC 220 V, Three Phase, 60 Hz
- Overall Dimensions: 110″ x 70″ x 80″ High
- Overall Dimensions: 130″ x 70″ x 80″ High with Chip Conveyor
- Weight : 12,000 lbs Approx.
