| Make: | Tos Varnsdorf |
| Model: | WHQ-13 |
| Year: | 2019 |
| Features: |
|---|
| Fanuc 31i-M Series CNC Control |
| Operator’s Platform Vertically and Horizontally Adjustable |
| 5.11″ Spindle Diameter |
| 4th Axis Rotary Table |
| 55,115 lbs Heavy Table Load Capacities |
| M16D24 FCS Hole Fixture Added on The Table |
| Through Spindle Coolant – 1000 psi |
| CAT-50 Taper, 3,000 Spindle RPM |
| Temperature Sensors on The Main Spindle Bearings |
| “HEIDENHAIN” Measuring Scales on Linear Axes X, Y, Z and R Spindle and Linear Axis W |
| 60 Station Automatic Tool Changer |
| Renishaw Tool Probe |
| Renishaw Tool Presetter |
| Angle Plate Set |
| Automatic Lubrication System |
| Coolant System |
| Chip Conveyor |
| Travels: |
|---|
| X Axis (Table Traverse Travel): 137.79″ |
| Y Axis (Headstock Vertical Travel): 98.42″ |
| Z Axis (Table Longitudinal Travel): 86.61″ |
| W Axis (Spindle Stroke): 31.49″ |
| B Axis (Rotary Table): Fully Controlled |
| X,Y,Z & W Axis Rapid Travers – 394 IPM |
| Rotary Table: |
|---|
| Length: 86.61″ |
| Width: 70.86″ |
| Max Weight on Table: 55,115 lbs |
| B Axis: Fully Controlled |
| Spindle: |
|---|
| Spindle Diameter: 5.11″ |
| Spindle Range: 3,000 RPM |
| Spindle Taper: CAT-50 |
| Power: 50 HP |
| Automatic Tool Changer: |
|---|
| Capacity: 60 Stations |
| Max Tool Diameter: 4.29″ – 12.59″ |
| Max Tool Length: 29.68″ |
| Max Tool Weight: 55.11 lbs |
| General: |
|---|
| Power: 220v / 3-Phase / 60 Hz |
| Machine Dimensions: 280″ x 210″ x 197″ High |
| Machine Weight: 85,000 lbs. Approx. |
