*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| SKU: | 112856 |
| Make: | Mazak |
| Model No.: | VC-500A/5X |
| Year of Manufacture: | 2019 |
| Equipped With: |
|---|
| Mazatrol SmoothX CNC Control |
| 5 Axis Simultaneous Machining |
| 15,000 RPM High Speed Spindle |
| Renishaw Probing System (Probe Needed) |
| Tool Presetter |
| Through Spindle Coolant |
| 30 Station Automatic Tool Changer |
| 30 HP High Torque Spindle |
| CAT-40 Taper Spindle |
| Spindle Chiller Unit |
| MPG Handwheel Control |
| Rigid Tapping |
| Coolant System |
| Chip Conveyor |
| Levelling Pads |
| Travels: |
|---|
| X-Axis: 21.85″ |
| Y-Axis: 19.88″ |
| Z-Axis: 20.07″ |
| B-Axis: ±110° ( Table Tilt ) |
| C Axis: 360° ( Table Rotate ) |
| Rapid Traverse Rates Axis: 1181 IPM |
| Spindle Nose to Table (Min.- Max.): 4.53″ – 24.61″ |
| Table: |
|---|
| Table Diameter: ø 19.69″ |
| Max Workpiece Size: ø 19.69″ x 12″ |
| Max Workpiece Weight: 441 lbs |
| Spindle: |
|---|
| Taper Size: CAT-40 |
| Speed Range: 15,000 RPM |
| Spindle Power: 30 HP |
| Automatic Tool Changer: |
|---|
| Capacity: 30 Tools |
| Max Tool Dia: 3.15″ -4.92″ |
| Max Tool Length: 10.23″ |
| Max Tool Weight: 17.63″ lbs |
| General: |
|---|
| Air Required: 80 psi, 4 scfm |
| Overall Dimensions: 118.45″ x 99.2″ x 118.11″ High |
| Weight: 14,000 lbs Approx. |
