*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Yama Seiki |
| Model: | GS-200Y |
| Year: | 2008 |
| Condition: | Used – Good |
| Equipped With: |
|---|
- Fanuc 18i-TB CNC Control
- Hydrobar Bar Feeder
- MicroCentric CB65-ND Collet Chuck (8″ Chuck Capable)
- A2-6, 4800 RPM Spindle
- Servo Controlled Full C Axis on Spindle
- 12 Station Live Tool Turret
- Y Axis on Turret
- Tool Presetter
- Parts Catcher
- Programmable Tailstock
- Spindle Chiller Unit
- Rigid Tapping
- PCMCIA Card Interface
- RS-232 Port
- Coolant System
- Chip conveyor
- Foot Switch
- Levelling Pads
- Books & Manuals
- Tool Holders Are Mounted On Turret (As shown in the images)
|
| Capacity: |
|---|
- Max Turning Diameter: 13.38″
- Max Turning Length: 23.62″
- Max Swing Over Bed: 18.50″
- Max Bar Capacity: 2.05″
|
| Travels: |
|---|
- X Axis Travel: 10.61″
- Y Axis Travel: 4.72″
- Z Axis Travel: 23.62″
- Rapid Traverse X Axis: 787 IPM
- Rapid Traverse Z Axis: 945 IPM
|
| Spindle: |
|---|
- Spindle Nose: A2-6
- Spindle Bore: 2.59″
- Spindle Speed: 4800 RPM
- Spindle Motor: 20 HP
|
| Turret: |
|---|
- Turret Capacity: 12 Stations
- Turret Index Time: 0.5 Second
- Live Tool Speed: 3000 RPM
- Live Tool Motor: 5 HP
- OD Tool Shank Size: 1″
- ID Tool Shank Size: 1.5″
|
| Tailstock: |
|---|
- Tailstock Taper: MT-3
- Tailstock Quill Diameter: 3.34″
- Tailstock Quill Stroke: 4.72″
- Tailstock Body Travel: 18.50″
|
| General: |
|---|
- Power: 50/60 HZ / 220v / 3-Phase
- Overall Dimensions: 106″ x 77″ x 75″ High Approx.
- Weight: 12,125 lbs
|
