*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us if you have any questions before making a purchase. All sales are final.*
| Make: | Citizen |
| Model: | L20 |
| Condition: | Used |
| Equipped With: |
|---|
| Sliding Headstock Design |
| Guide Bushing |
| Sub-Spindle |
| C-Axis on Main & Sub Spindles |
| Live Tooling |
| Automatic Lubrication System |
| Coolant System |
| Full Enclosure |
| Capacity: |
|---|
| Max Bar Capacity: 0.79″ |
| Max Machining Diameter: 0.79″ |
| Max Machining Length: 8.0″ |
| Spindles: |
|---|
| Main Spindle Speed: 10,000 RPM |
| Main Spindle Motor: 5.5 HP |
| Sub-Spindle Speed: 10,000 RPM |
| Sub-Spindle Motor: 5.5 HP |
| Tooling: |
|---|
| Number of Turning Tools: 6 |
| Number of Live Tools: 6 |
| Live Tool Speed: 8,000 RPM |
| Live Tool Motor: 1.5 HP |
| Axis Travels: |
|---|
| X-Axis Travel: 3.15″ |
| Z-Axis Travel: 8.27″ |
| Feedrates: |
|---|
| Rapid Traverse X/Z: 945 IPM |
| General: |
|---|
| Power Requirement: 220V / 3-Phase |
| Machine Weight (Approx.): 5,300 lbs |
| Footprint (Approx.): 70″ × 55″ |
