*All specifications are approximations and are subject to verification. Comes as shown in images. Please give us a call if you have any questions before purchasing. All sales are final.*
| SKU | 2208 |
| Make | DOOSAN |
| Model No. | DHM-630 |
| Serial # | HM630302 |
| Year | 2007/09 |
| Cutting Time: | 3489 Hours |
| Condition: | Very Good |
| Equipped With: |
|---|
| Fanuc 18-iM CNC Control |
| Full 4th Axis |
| 6,000 RPM High Torque Spindle |
| Through Spindle Coolant ? |
| Twin Pallet Changer |
| 90 Station Tool Changer ( Upgrade ) |
| Box Ways Construction |
| PCMCIA Card Interface |
| Upgraded Memory |
| Pallet Seat Detection |
| Spindle Orientation |
| Rigid Tapping |
| Helical Interpolation |
| Fast Rapid Traverse Rate |
| Flood coolant with large coolant tank |
| Chip Conveyor |
| Table: |
|---|
| Length: 24.8″ |
| Width: 24.8″ |
| Max Weight on Table: 2640 lbs |
| Max Workpiece Width X Height: 41.3″ X 53.1″ |
| Index Time: 8.5 seconds |
| Travels: |
|---|
| X Axis: 39.4″ |
| Y Axis: 31.5″ |
| Z Axis: 33.4″ |
| B Axis: 0.001° ( Full 4th ) |
| Spindle Nose to Table Center: 5.9″ – 43.3″ |
| Spindle Center to Table Top: 2.9″ – 36.4″ |
| Spindle: |
|---|
| Taper Size: 50 |
| Max. Speed: 6,000 RPM |
| Power: 50 HP |
| Torque: 1278 ft/lb |
| Features: |
|---|
| Rapid X & Y : 1417 Inch Per Minute |
| Rapid Z : 1417 Inch Per Minute |
| Cutting Feedrate: 945 Inch Per Minute |
| Tool changer: |
|---|
| Capacity: 90 Tools |
| Taper: 50 |
| Max Tool Size: 12.6″ |
| Max Tool Length: 24.8″ |
| Max Tool Weight: 66.5 lbs. |
| Tool Change Time: 2 Second |
| General: |
|---|
| Air Required: 90 psi, 4 scfm |
| Power: 75kva / 480v / 3-Phase |
| Overall Dimensions: 270″ X 144″ x 130″ High ? |
| Weight: 41,000 lbs |
