*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | DOOSAN |
| Model: | LYNX 220A |
| Machine Type: | CNC Turning Center |
| CNC Control: | FANUC i-Series CNC Control |
| Equipped With: |
|---|
| FANUC i-Series CNC Control |
| 8″ 3-Jaw Chuck |
| 12-Station Turret |
| Tailstock |
| Parts Catcher |
| Chip Conveyor |
| Fully Enclosed Work Area |
| Automatic Lubrication System |
| Coolant System |
| Slant-Bed CNC Turning Center |
| Turning Capacity: |
|---|
| Maximum Swing Over Bed: 20.1″ |
| Maximum Turning Diameter: 12.6″ |
| Maximum Turning Length: 12.7″ |
| Chuck Size: 8″ |
| Spindle Bore: 2.08″ |
| Spindle Nose: A2-5 |
| Travels: |
|---|
| X-Axis Travel: 8.00″ |
| Z-Axis Travel: 13.38″ |
| Spindle: |
|---|
| Maximum Spindle Speed: 6,000 RPM |
| Spindle Motor: 20 HP |
| Spindle Bore: 2.08″ |
| Spindle Nose: A2-5 |
| Spindle Speed Range: 6,000 RPM |
| Turret: |
|---|
| Turret Capacity: 12 Stations |
| Chuck: 8″ 3-Jaw Chuck |
| General: |
|---|
| Machine Type: Horizontal CNC Turning Center |
| Number of Axes: 2 |
