*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Doosan |
| Model: | PUMA 2600 |
| Year: | 2011 |
| Equipped With: |
|---|
| Fanuc Oi-TD CNC Control |
| 10″ Samchully Hydraulic Chuck |
| Tool Presetter |
| Tailstock |
| 12-Station Turret |
| Turbo Chip Conveyor |
| Available Manuals |
| Enclosed Machine Guarding |
| Coolant System |
| Capacity: |
|---|
| Chuck Size: 10″ |
| Swing Over Bed: 30.70″ |
| Maximum Turning Diameter: 18.93″ |
| Maximum Turning Length: 29.90″ |
| Travels: |
|---|
| X-Axis Travel: 10.20″ |
| Z-Axis Travel: 32.70″ |
| Rapid Traverse X-Axis: 1,181 IPM |
| Rapid Traverse Z-Axis: 1,181 IPM |
| Spindle: |
|---|
| Spindle Nose: A2-8 |
| Maximum Spindle Speed: 3,500 RPM |
| Spindle Motor: 30 HP |
| Turret: |
|---|
| Turret Type: Servo Turret |
| Turret Capacity: 12 Stations |
| General: |
|---|
| Power Source: 220v / 3-Phase / 60 Hz |
| Machine Dimensions (Approx.): 142″ L × 75″ W × 73″ H |
| Machine Weight (Approx.): 11,900 lb |
