*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | FANUC |
| Model: | ROBODRILL α-T21iFLA |
| Year: | 2010 |
| Machine Type: | CNC Drill/Tap Vertical Machining Center |
| Control: | FANUC Series 31i-A5 |
| Features: |
|---|
| FANUC Series 31i-A5 CNC Control |
| 21-Position Automatic Tool Changer |
| A-B Pallet Shuttle Unit |
| 10,000 RPM Spindle |
| BT-30 Spindle Taper |
| Coolant System |
| Pallet Changer |
| Travels: |
|---|
| X-Axis Travel: 27.5″ |
| Y-Axis Travel: 15.75″ |
| Z-Axis Travel: 12.99″ |
| Table: |
|---|
| Table Size: 33.5″ × 16.1″ |
| Spindle: |
|---|
| Spindle Speed: 10,000 RPM |
| Spindle Taper: BT-30 |
| Automatic Tool Changer: |
|---|
| Capacity: 21 Tools |
| Tool Change Time: 0.9 sec. |
| Feedrates: |
|---|
| Rapid Traverse: 2,125 IPM |
| General: |
|---|
| Power Source: 220v / 3-Phase / 50–60 Hz |
| Overall Dimensions (Approx.): 110″ × 80″ × 96″ H |
| Machine Weight (Approx.): 6,000 lbs. |
