*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model No.: | ST-10 |
| Year of Manufacture: | 2015 |
| Machine Type: | CNC Turning Center |
| Control: | Haas CNC Control |
| Country of Origin: | USA |
| Equipped With: |
|---|
| 12-Station Turret |
| 6″ Hydraulic Chuck |
| High-Speed Spindle |
| Coolant System |
| Full Enclosure |
| Capacity: |
|---|
| Max Turning Diameter: 14″ |
| Max Turning Length: 16″ |
| Swing Over Bed: 16.25″ |
| Bar Capacity: 1.75″ |
| Travels: |
|---|
| X-Axis Travel: 7.9″ |
| Z-Axis Travel: 14″ |
| Spindle: |
|---|
| Spindle Speed: 6,000 RPM |
| Spindle Motor: 15 HP |
| Spindle Nose: A2-5 |
| Spindle Bore: 2.31″ |
| Tooling: |
|---|
| Turret Capacity: 12 Stations |
| Tooling Type: Bolt-On Tooling |
| Feed Rates: |
|---|
| Rapid Traverse (X): 945 IPM |
| Rapid Traverse (Z): 945 IPM |
| General: |
|---|
| Power Source: AC 220 V, 3-Phase, 60 Hz |
| Machine Dimensions (L x W x H): 98″ x 69″ x 73″ |
| Machine Weight: 7,500 lbs Approx. |
