*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: |
HAAS |
| Model No.: |
VF-4SS |
| Year of Manufacture: |
2015 |
| Condition: |
Used – Good |
| Machine Type: |
CNC Vertical Machining Center (High-Speed) |
| CNC Control: |
HAAS CNC Control |
| Country of Origin: |
USA |
| Equipped With: |
| HAAS CNC Control |
| 12,000 RPM Inline Direct-Drive Spindle |
| 40 Taper Spindle |
| High-Speed Machining (Super Speed) |
| Side Mount Tool Changer (SMTC) |
| Chip Conveyor |
| Programmable Coolant |
| Rigid Tapping |
| USB & Ethernet Connectivity |
| Full Enclosure |
| Capacity: |
| Table Size: 52″ x 18″ |
| Table Load Capacity: 3,500 lbs |
| Travels: |
| X-Axis Travel: 50″ |
| Y-Axis Travel: 20″ |
| Z-Axis Travel: 25″ |
| Spindle: |
| Spindle Speed: 12,000 RPM |
| Spindle Taper: CAT 40 |
| Spindle Motor: Approx. 30 HP |
| Drive Type: Inline Direct Drive |
| Feed Rates: |
| Rapid Traverse (X/Y): 1,400 IPM |
| Rapid Traverse (Z): 1,400 IPM |
| Cutting Feed Rate: Programmable |
| Tool Changer: |
| Tool Capacity: 24+1 SMTC |
| Tool Holder Type: CAT 40 |
| Tool Change Type: Automatic |
| Electrical: |
| Voltage: 195–260V |
| Phase: 3 Phase |
| Frequency: 50/60 Hz |
| Full Load: 80 Amps |
| Dimensions: |
| Floor Space: Approx. 120″ x 100″ x 110″ |
| Machine Weight: Approx. 13,500 lbs |
