Johnford SV-24 CNC Vertical Machining Center

SKU 11810

Make/Model Johnford SV-24

Year 2000

Video On Request

Out of stock

SKU:	11810
Make/Model:	Johnford SV-24
Year:	2000
Video:	On Request

SKU: 11810

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	Johnford
Model:	SV-24
Year:	2000
Machine Type:	CNC Vertical Machining Center

Features:
Fanuc Series 18-M CNC Control
24-Position Automatic Tool Changer
Chip Conveyor
Coolant System
CAT 40 Tooling

Capacity:
Table Width: 18″
Table Length: 32″
Table Size: 32″ × 18″

Travels:
X-Axis Travel: 24″
Y-Axis Travel: 20″
Z-Axis Travel: 24″
Rapid Traverse: 1,500 IPM

Spindle:
Spindle Taper: CAT 40
Spindle Speed: 8,000 RPM
Spindle Motor: 15 HP

Automatic Tool Changer:
Tool Capacity: 24 Positions
ATC Type: Dual Swing Arm

General:
Machine Weight (Approx.): 13,225 lbs.
Machine Dimensions (Approx.): 118″ × 118″ × 106″

Capacity:
Table Width: 457 mm
Table Length: 813 mm
Table Size: 813 mm × 457 mm

Travels:
X-Axis Travel: 610 mm
Y-Axis Travel: 508 mm
Z-Axis Travel: 610 mm
Rapid Traverse: 1,500 IPM

Spindle:
Spindle Taper: CAT 40
Spindle Speed: 8,000 RPM
Spindle Motor: 15 HP

Automatic Tool Changer:
Tool Capacity: 24 Positions
ATC Type: Dual Swing Arm

General:
Machine Weight (Approx.): 13,225 lbs.
Machine Dimensions (Approx.): 2,997 mm × 2,997 mm × 2,692 mm

Categories	CNC Vertical Machining Centers
Make	JOHNFORD
Model	SV-24

Fanuc Series 18-M CNC Control
24-Position Automatic Tool Changer
Chip Conveyor
Coolant System
CAT 40 Tooling
