*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: |
Kitamura |
| Model No.: |
Mycenter-2XiF |
| Condition: |
Used – Good |
| Machine Type: |
CNC Vertical Machining Center |
| CNC Control: |
Fanuc 16i-MB |
| Country of Origin: |
Japan |
| Equipped With: |
| Fanuc 16i-MB CNC Control |
| 20,000 RPM High-Speed Spindle |
| BT40 / Big Plus Spindle |
| 24 Station Automatic Tool Changer |
| Spark Changer (Pallet System) |
| High-Speed Machining Capability |
| Coolant System |
| Full Enclosure |
| Chip Conveyor (optional) |
| Capacity: |
| Table Size: ~786 × 355 mm |
| Max Table Load: ~240 kg |
| Travels: |
| X-Axis Travel: ~510 mm |
| Y-Axis Travel: ~355 mm |
| Z-Axis Travel: ~460 mm |
| Rapid Traverse (X/Y): ~50 m/min |
| Rapid Traverse (Z): ~36 m/min |
| Spindle: |
| Spindle Speed: Up to 20,000 RPM |
| Spindle Taper: BT40 / Big Plus |
| Spindle Motor: ~13–15 kW (≈15–20 HP) |
| Tooling System: |
| Tool Capacity: 24 Tools |
| Type: Arm / Side Mount ATC |
| Fast tool-to-tool change (~1.7 sec typical) |
| General: |
| Axis: 3-Axis |
| Machine Weight: ~5,500 – 5,700 kg |
| Power Requirement: ~25 kVA |
| Footprint: ~2.4 × 2.5 m |
| Features: |
| Ultra-high speed spindle (20K RPM) |
| Designed for aluminum & precision parts |
| Spark changer = palletized production (high productivity) |
| Japanese build quality (very high accuracy & reliability) |
| Compact footprint but high performance |
