*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Laguna |
| Model: | Swift MT (Multi-Tool) |
| Year: | 2022 |
| Condition: | Used – Good |
| Machine Type: | CNC Router / Multi-Tool CNC |
| Features: |
|---|
- Laguna / WinCNC PC-Based Control System
- Industrial Liquid-Cooled Spindle
- Multi-Tool Capable (Routing, Cutting, Knife Work)
- Phenolic Vacuum Table with Multiple Zones
- Helical Rack & Pinion Drive System
- Precision Ball Screw Z-Axis
- Heavy-Duty Welded Steel Frame
- Automatic Tool Touch-Off Pad
- Dust Collection Port
- Caterpillar Cable Management System
|
| Work Area: |
|---|
- Available Table Sizes: 4′ × 4′ / 4′ × 8′ / 5′ × 10′
- Gantry Clearance: Approx. 7″
- Gantry Height: Approx. 12″
|
| Spindle: |
|---|
- Spindle Power: 3 HP
- Spindle Type: Liquid-Cooled Industrial Spindle
- Speed Range: 6,000 – 24,000 RPM
- Collet Type: ER-Style Collets
- Cooling System: External Water Pump & Reservoir
|
| Motion System: |
|---|
- Axes: 3-Axis (X / Y / Z)
- X & Y Drive: Helical Rack & Pinion
- Z-Axis Drive: Precision Ground Ball Screw
- Linear Motion: Heavy-Duty Linear Bearings
- Rapid Traverse: Up to 900 IPM
- Max Cutting Speed: Up to 600 IPM
|
| Table & Vacuum System: |
|---|
- Table Type: Phenolic Grid-Style Vacuum Table with T-Slots
- Vacuum Zones: 4–6 Independently Controlled Zones
- Vacuum Control: Adjustable Valve System
- Dust Port Size: 4″ Diameter
|
| Control & Software: |
|---|
- Controller: Laguna / WinCNC
- PC-Based Interface with Keyboard, Monitor & Mouse
- File Formats Supported: G-Code, DXF, HPGL
- Manual & Automatic Tool Length Measurement
- Incremental & Continuous Jogging
|
| Electrical: |
|---|
- Power Requirement: 200–220V
- Approx. Amperage: 40 Amps
- Phase: 3-Phase or Single-Phase (Vacuum Dependent)
|
| Optional / Configurable: |
|---|
- Tangential Knife System (TCM-3)
- Laguna Vision Registration System
- 3D Scanning / Digitizing Capability
- Edge Outlining & Probing
- Automatic Vacuum Zoning
|
