*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us if you have any questions before making a purchase. All sales are final.*
| Make: | Mazak |
| Model: | SVC-2000L/120-II |
| Condition: | Used |
| Machine Type: |
|---|
| Linear Motor Drive Vertical Machining Center |
| Traveling Column / Fixed Table Construction |
| Designed for High-Speed, High-Accuracy Machining of Long Workpieces |
| Travels: |
|---|
| X-Axis Travel: 120.0″ |
| Y-Axis Travel: 20.08″ |
| Z-Axis Travel: 20.08″ |
| Spindle Nose to Table: 7.09″ – 27.17″ |
| Column Clearance: 20.08″ |
| Table: |
|---|
| Table Size: 133.86″ × 20.08″ |
| Max Table Load (Even): 5,291 lbs |
| T-Slots: 5 × 0.71″ |
| T-Slot Pitch: 3.94″ |
| Spindle: |
|---|
| Spindle Speed Range: 50 – 15,000 RPM |
| Spindle Taper: No. 40 (7/24) |
| Spindle Bearing ID: 2.76″ |
| Spindle Acceleration (0–15,000 RPM): 1.15 sec |
| Gear Range: Stepless |
| Spindle Motor: |
|---|
| 30-Min Rating: 30 HP |
| Continuous Rating: 20 HP |
| Feedrates: |
|---|
| Rapid Traverse X-Axis: 4,724 IPM |
| Rapid Traverse Y/Z-Axis: 1,969 IPM |
| Cutting Feedrate (X/Y/Z): 0 – 1,181 IPM |
| Automatic Tool Changer: |
|---|
| Tool Shank: No. 40 |
| Magazine Capacity: 30 Tools |
| Max Tool Diameter: 3.15″ |
| Max Tool Diameter (Adjacent Empty): 4.33″ |
| Max Tool Length: 13.78″ |
| Max Tool Weight: 18 lbs |
| Tool Selection: MAZATROL Random Memory |
| Tool Change Time (Chip-to-Chip): 4.0 sec |
| CNC Control: |
|---|
| MAZATROL SmoothG CNC Control |
| 2–4 Axis Simultaneous Control |
| 19″ Touchscreen Display (SXGA) |
| Minimum Input Increment: 0.00001″ |
| Program Capacity: 256 Programs (Up to 960) |
| Memory: 2 MB (Expandable to 8 MB / 32 MB) |
| Interpolation: Linear, Circular, Helical, Spiral, Cylindrical*, NURBS* |
| Smooth Corner Control |
| Variable Acceleration Control |
| Shape Compensation |
| Connectivity: Ethernet, USB, SD Card |
| General: |
|---|
| Power Requirement (15 Min): 75.1 kVA |
| Power Requirement (Continuous): 65.1 kVA |
| Air Pressure Required: 73 PSI |
| Air Flow Required: 16.2 CFM |
| Machine Height: 102.36″ |
| Floor Space Required: 235.63″ × 145.98″ |
| Machine Weight (Approx.): 28,660 lbs |
