*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Mitsubishi |
| Model: | M-V5B |
| Year: | 1995 |
| Machine Type: | CNC Vertical Machining Center |
| CNC Control: | MELDAS 500 |
| Features: |
|---|
| MELDAS 500 CNC Control |
| CAT 40 Spindle Taper |
| 18-Position Automatic Tool Changer (ATC) |
| AC-Cooled Spindle |
| Helical-Threaded Spindle Configuration |
| Expanded Control Memory |
| Coolant System |
| Enclosed Machining Area with Viewing Window |
| Spindle Load Display |
| Feedrate and Spindle Speed Override Controls |
| Manual Handwheel |
| Emergency-Stop Button |
| Work Area Lighting Control |
| Chip Conveyor Controls |
| Table: |
|---|
| Table Size: 39.4″ × 20.1″ |
| Maximum Table Load: 1,100 lbs |
| Travels: |
|---|
| X-Axis Travel: 31.5″ |
| Y-Axis Travel: 20.1″ |
| Z-Axis Travel: 18.1″ |
| Feedrates: |
|---|
| Maximum Feed Rate: 393 IPM |
| X-Axis Rapid Traverse: 1,181 IPM |
| Y-Axis Rapid Traverse: 1,181 IPM |
| Z-Axis Rapid Traverse: 787 IPM |
| Spindle: |
|---|
| Spindle Speed Range: 80–8,000 RPM |
| Spindle Taper: CAT 40 |
| Spindle Motor Power: 10 HP |
| Automatic Tool Changer: |
|---|
| Tool Changer Capacity: 18 Tools |
| Tool Change Time: 1.5 Seconds |
| Electrical: |
|---|
| Electrical Supply: 200–220 V |
| Phase: 3-Phase |
