OKK VM5 III CNC Vertical Machining Center
Out of stock
| Location: | Byron, IL |
| SKU: | 2283 |
| Make/Model: | OKK VM5 III |
| Video: | No Video |
| SKU: | 2283 |
| Make: | OKK |
| Model: | VM5 III |
| Year: | 2006 |
| Cutting Time: | Only |
| Features: |
|---|
| Fanuc 180is-MB series CNC Control |
| Box Way construction |
| 20 Station Automatic tool changer |
| 10,000 RPM Spindle |
| PCMCIA Card Slot |
| RS-232 Port |
| MPG Handwheel Control |
| Rigid Tapping |
| Telescopic way covers |
| Coolant Tank |
| Travels: |
|---|
| X-Axis: 40.15″ |
| Y-Axis: 20.08″ |
| Z-Axis: 20.08″ |
| Spindle Nose to Table (Min.- Max.): 4.5″ – 24.5″ |
| Table: |
|---|
| Length: 48″ |
| Width: 20″ |
| Max Weight on Table: 3000 lbs |
| Spindle: |
|---|
| Taper Size: 40 |
| Speed Range: 10,000 RPM |
| Spindle Power: 15 HP |
| Automatic Tool Changer: |
|---|
| 40 Taper |
| Capacity: 20 Station |
| Tool Weight: 15 lbs |
| Max Tool Length: 15″ |
| Max Tool Dia.: 4.33″ |
| Feed rates: |
|---|
| Rapid Traverse rates: 900 IPM |
| Cutting Feedrate: 400 IPM |
| General: |
|---|
| Air Required: 80 psi, 4 scfm |
| Power: 220v / 3-Phase |
| Overall Dimensions: 122″ x 100″ x 100″ High |
| Weight: 12,500 lbs |
