OKK HM600 4-Axis CNC Horizontal Machining Center

SKU 11725

Make/Model OKK HM 600

Condition Used - Good

Video On Request

Out of stock

SKU:	11725
Make/Model:	OKK HM 600
Condition:	Used – Good
Video:	On Request

SKU: 11725

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	OKK
Model:	HM600

Features:
Fanuc Series 310iS-A CNC Control
Full B-Axis Rotary Table
(2) 24.8″ × 24.8″ Pallets
60-Position Automatic Tool Changer
CAT 50 Spindle Taper
Through-Spindle Coolant (TSC)
Spindle Chiller
Hydraulic Workpiece Clamping
Chip Conveyor

Travels:
X-Axis Travel: 30.7″
Y-Axis Travel: 29.5″
Z-Axis Travel: 31.5″

Pallet:
Number of Pallets: 2
Pallet Size: 24.8″ × 24.8″
B-Axis: Full 360°

Spindle:
Spindle Speed: 13,000 RPM
Spindle Taper: CAT 50

Automatic Tool Changer:
Tool Capacity: 60 Tools

General:
Machine Type: 4-Axis Horizontal Machining Center
Machine Dimensions (Approx.): 220″ × 165″ × 145″
Machine Weight (Approx.): 34,000 lbs

Travels:
X-Axis Travel: 780 mm
Y-Axis Travel: 749 mm
Z-Axis Travel: 800 mm

Pallet:
Number of Pallets: 2
Pallet Size: 630 mm × 630 mm
B-Axis: Full 360°

Spindle:
Spindle Speed: 13,000 RPM
Spindle Taper: CAT 50

Automatic Tool Changer:
Tool Capacity: 60 Tools

General:
Machine Type: 4-Axis Horizontal Machining Center
Machine Dimensions (Approx.): 5,588 mm × 4,191 mm × 3,683 mm
Machine Weight (Approx.): 34,000 lbs

Categories	CNC Horizontal Machining Center
Make	OKK
Model	HM 600

Fanuc Series 310iS-A CNC Control
Full B-Axis Rotary Table
(2) 630 mm × 630 mm Pallets
60-Position Automatic Tool Changer
CAT 50 Spindle Taper
Through-Spindle Coolant (TSC)
Spindle Chiller
Hydraulic Workpiece Clamping
Chip Conveyor

Payment Terms

A booking deposit secures the machine, with the remaining balance due prior to loading or shipment. We accept bank transfer, wire transfer, and approved payment methods.
