Name: Shibaura BT-8CR Horizontal Table Type Boring Mill
Brand: SHIBAURA
SKU: 113625
Price: 999 USD
Availability: InStock

Shibaura BT-8CR Horizontal Table Type Boring Mill

Reserve your machine by paying: $999 (Refundable)

(We’ll hold it for 7 business days while you inspect or finalize your purchase)

$999

Location Lake Elsinore, CA

SKU 113625

Make SHIBAURA

Model BT-8CR

Year 1971

Condition Used

In stock

Location:	Lake Elsinore, CA
SKU:	113625
Make:	SHIBAURA
Model:	BT-8CR
Year:	1971
Condition:	Used

SKU: 113625

Brand: SHIBAURA

Disclaimer: All specifications are approximate and provided for reference only, based on the machine photographs and published model information. The buyer must verify all details before purchase. Accessories shown are included only if listed on the invoice.

Make:	Toshiba Shibaura
Model:	BT-8CR
Country of Manufacture:	Japan

Equipped With:
Teledyne Gurley Pathfinder 50 Digital Readout
3.15″ Spindle Diameter
Built-In Rotary Table
Tailstock

Table:
Rotary Table Size: 35.43″ × 41.33″
Table Type: Built-In Rotary
Table Rotation: 360°

Travels:
Cross Travel (X-Axis): 39.4″
Vertical Headstock Travel (Y-Axis): 31.5″
Longitudinal Table Travel (Z-Axis): 31.5″
Spindle Travel: 19.68″

Spindle:
Spindle Diameter: 3.15″
Spindle Travel: 19.68″
Spindle Speed Range: 20 – 1,000 RPM
Main Motor: 12 HP

General:
Approximate Overall Dimensions: 151″ × 87″ × 99″ High
Approximate Machine Weight: 18,600 lbs

Equipped With:
Teledyne Gurley Pathfinder 50 Digital Readout
80 mm Spindle Diameter
Built-In Rotary Table
Tailstock

Table:
Rotary Table Size: 900 mm × 1,050 mm
Table Type: Built-In Rotary
Table Rotation: 360°

Travels:
Cross Travel (X-Axis): 1,001 mm
Vertical Headstock Travel (Y-Axis): 800 mm
Longitudinal Table Travel (Z-Axis): 800 mm
Spindle Travel: 500 mm

Spindle:
Spindle Diameter: 80 mm
Spindle Travel: 500 mm
Spindle Speed Range: 20 – 1,000 RPM
Main Motor: 12 HP

General:
Approximate Overall Dimensions: 3,835 mm × 2,210 mm × 2,515 mm High
Approximate Machine Weight: 18,600 lbs

Make	SHIBAURA
Model	BT-8CR
Categories	CNC Boring Mill

Shibaura BT-8CR Horizontal Table Type Boring Mill 1

Shibaura BT-8CR Horizontal Table Type Boring Mill 2

Shibaura BT-8CR Horizontal Table Type Boring Mill 3

Shibaura BT-8CR Horizontal Table Type Boring Mill 4

Shibaura BT-8CR Horizontal Table Type Boring Mill 5

Shibaura BT-8CR Horizontal Table Type Boring Mill 6

Shibaura BT-8CR Horizontal Table Type Boring Mill 7

Shibaura BT-8CR Horizontal Table Type Boring Mill 8

Shibaura BT-8CR Horizontal Table Type Boring Mill 9

Shibaura BT-8CR Horizontal Table Type Boring Mill 10

Shibaura BT-8CR Horizontal Table Type Boring Mill 11

Shibaura BT-8CR Horizontal Table Type Boring Mill 12

Shibaura BT-8CR Horizontal Table Type Boring Mill 13

Shibaura BT-8CR Horizontal Table Type Boring Mill 14

Payment Terms

A booking deposit secures the machine, with the remaining balance due prior to loading or shipment. We accept bank transfer, wire transfer, and approved payment methods.
