*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | YCM |
| Model No.: | WV108A |
| Year of Manufacture: | 2010 |
| Machine Type: | CNC Vertical Machining Center |
| CNC Control: | Fanuc CNC Control |
| Country of Origin: | Taiwan |
| Equipped With: |
|---|
| Fanuc CNC Control |
| 10,000 RPM Spindle |
| Automatic Tool Changer |
| Coolant System |
| Chip Conveyor |
| Full Enclosure |
| Meehanite Cast Construction |
| Capacity: |
|---|
| Table Size: 48″ x 20″ |
| Max Table Load: 1,500 lbs |
| Travels: |
|---|
| X-Axis Travel: 40″ |
| Y-Axis Travel: 20″ |
| Z-Axis Travel: 20″ |
| Spindle: |
|---|
| Spindle Speed: 10,000 RPM |
| Spindle Taper: CAT 40 |
| Spindle Motor: 15 HP (Approx.) |
| Tooling: |
|---|
| ATC Capacity: 24 Tools (Approx.) |
| General: |
|---|
| Power Source: AC 220/440 V, 3-Phase, 50/60 Hz |
| Machine Dimensions (L x W x H): 110″ x 95″ x 105″ |
| Machine Weight: 11,000 lbs Approx. |
