Mazak VCN 530C-II CNC Vertical Machining Center – TSC, 12,000 RPM Mill
Location
Lake Elsinore, CA
SKU
113667
Make
MAZAK
Model
VCN 530C-II
Year
2015
Condition
Used
In stock
| Location: | Lake Elsinore, CA |
| SKU: | 113667 |
| Make: | MAZAK |
| Model: | VCN 530C-II |
| Year: | 2015 |
| Condition: | Used |
Add to WishlistRemove from Wishlist
Add to Wishlist
Disclaimer: All specifications and hours are approximate and for reference only, often based on manufacturer literature. Buyer must verify all details prior to purchase. Accessories shown are included only if listed on the invoice.
| SKU: | 113667 |
| Make: | Mazak |
| Model: | VCN 510C-II |
| Equipped With: |
|---|
| Mazatrol Matrix Nexus 2 CNC Control |
| 12,000 RPM High-Speed Spindle |
| Through Spindle Coolant |
| 30-Station Automatic Tool Changer |
| CAT-40 Taper Spindle |
| Renishaw Receiver Installed |
| Tool Presetter |
| 25 HP High-Torque Spindle |
| MPG Handwheel Control |
| USB Ports |
| Rigid Tapping |
| Spindle Chiller Unit |
| Automatic Lubrication Unit |
| Coolant Tank |
| Chip Conveyor |
| Books & Manuals |
| Travels: |
|---|
| X-Axis Travel: 41.3″ |
| Y-Axis Travel: 20.8″ |
| Z-Axis Travel: 20.8″ |
| Rapid Traverse Rates: 1,417 IPM |
| Cutting Feed Rates: 787 IPM |
| Spindle Nose to Table (Min.-Max.): 5.9″ – 26″ |
| Table: |
|---|
| Length: 51.18″ |
| Width: 21.65″ |
| Number of Standard T-Slots: 5 |
| T-Slot Width: 5/8″ |
| Maximum Weight on Table: 2,646 lbs |
| Spindle: |
|---|
| Taper Size: CAT-40 |
| Speed Range: 12,000 RPM |
| Spindle Type: Direct Drive |
| Spindle Power: 25 HP |
| Automatic Tool Changer: |
|---|
| Capacity: 30-Station Side Mounted |
| Maximum Tool Weight: 17.63 lbs |
| Maximum Tool Diameter: 3.15″ |
| Maximum Tool Length: 13.78″ |
| Tool Changing Time: 1.3 Seconds |
| General: |
|---|
| Air Required: 80 psi, 4 scfm |
| Power: 208V / 35 kVA / 3-Phase / 50/60 Hz |
| Overall Dimensions: 120″ × 112″ × 114″ High |
| Weight: 15,180 lbs |
| Equipped With: |
|---|
| Mazatrol Matrix Nexus 2 CNC Control |
| 12,000 RPM High-Speed Spindle |
| Through Spindle Coolant |
| 30-Station Automatic Tool Changer |
| CAT-40 Taper Spindle |
| Renishaw Receiver Installed |
| Tool Presetter |
| 25 HP High-Torque Spindle |
| MPG Handwheel Control |
| USB Ports |
| Rigid Tapping |
| Spindle Chiller Unit |
| Automatic Lubrication Unit |
| Coolant Tank |
| Chip Conveyor |
| Books & Manuals |
| Travels: |
|---|
| X-Axis Travel: 1,049 mm |
| Y-Axis Travel: 528 mm |
| Z-Axis Travel: 528 mm |
| Rapid Traverse Rates: 1,417 IPM |
| Cutting Feed Rates: 787 IPM |
| Spindle Nose to Table (Min.-Max.): 150 mm – 660 mm |
| Table: |
|---|
| Length: 1,300 mm |
| Width: 550 mm |
| Number of Standard T-Slots: 5 |
| T-Slot Width: 5/203 mm |
| Maximum Weight on Table: 2,646 lbs |
| Spindle: |
|---|
| Taper Size: CAT-40 |
| Speed Range: 12,000 RPM |
| Spindle Type: Direct Drive |
| Spindle Power: 25 HP |
| Automatic Tool Changer: |
|---|
| Capacity: 30-Station Side Mounted |
| Maximum Tool Weight: 17.63 lbs |
| Maximum Tool Diameter: 80 mm |
| Maximum Tool Length: 350 mm |
| Tool Changing Time: 1.3 Seconds |
| General: |
|---|
| Air Required: 80 psi, 4 scfm |
| Power: 208V / 35 kVA / 3-Phase / 50/60 Hz |
| Overall Dimensions: 3,048 mm × 2,845 mm × 2,896 mm High |
| Weight: 15,180 lbs |
| Make | Mazak |
|---|---|
| Model | VCN 530C-II |
| Categories | CNC Vertical Machining Centers |
