Akira Seiki RMV500APC 2-Pallet CNC Vertical Machining Center

SKU 11761

Make/Model Akira Seiki RMV500APC

Year 2009

Video On Request

Out of stock

SKU:	11761
Make/Model:	Akira Seiki RMV500APC
Year:	2009
Video:	On Request

SKU: 11761

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	Akira Seiki
Model:	RMV500APC
Year:	2009
Machine Type:	CNC Vertical Machining Center

Features:
AKIRA Mi645 CNC Control
2-Pallet Automatic Pallet Changer
24+1 Tool Capacity
Servo Tool Magazine
Chip Conveyor
Coolant System
Full Enclosure
Automatic Lubrication
Tool Measurement Capability
Pallet Positioning System

Travels:
X-Axis Travel: 19.69″
Y-Axis Travel: 11.81″
Z-Axis Travel: 11.02″
Spindle Nose to Table: 5.91″–16.93″
Rapid Traverse X/Y/Z: 2,362 / 2,362 / 3,779 IPM
Cutting Feed X/Y/Z: 394 / 394 / 394 IPM

Table:
Pallet Size: 19.69″ × 11.81″
Maximum Pallet Load: 220 lbs
Number of Pallets: 2
Pallet Change Time: Approx. 1.5 sec. / 180°

Spindle:
Spindle Speed: 15,000 RPM
Maximum Optional Speed: 20,000 RPM
Spindle Motor Output: 10 HP
Spindle Taper: HSK40A
Rigid Tapping: Up to 8,000 RPM

Automatic Tool Changer:
Tool Storage Capacity: 24+1
Tool Magazine: Servo Type
Maximum Tool Diameter: 1.97″
Maximum Tool Length: 6.89″
Maximum Tool Weight: Approx. 6 lbs
Tool Change Time: T-T 0.7 sec. / C-C 2.1 sec.

General:
Machine Weight (Approx.): 9,259 lbs
Machine Dimensions (Approx.): 59.06″ W × 106.30″ L
Power Requirement: 11 kVA
Air Pressure Requirement: 87 PSI

Travels:
X-Axis Travel: 500 mm
Y-Axis Travel: 300 mm
Z-Axis Travel: 280 mm
Spindle Nose to Table: 150 mm–430 mm
Rapid Traverse X/Y/Z: 2,362 / 2,362 / 3,779 IPM
Cutting Feed X/Y/Z: 394 / 394 / 394 IPM

Table:
Pallet Size: 500 mm × 300 mm
Maximum Pallet Load: 220 lbs
Number of Pallets: 2
Pallet Change Time: Approx. 1.5 sec. / 180°

Spindle:
Spindle Speed: 15,000 RPM
Maximum Optional Speed: 20,000 RPM
Spindle Motor Output: 10 HP
Spindle Taper: HSK40A
Rigid Tapping: Up to 8,000 RPM

Automatic Tool Changer:
Tool Storage Capacity: 24+1
Tool Magazine: Servo Type
Maximum Tool Diameter: 50 mm
Maximum Tool Length: 175 mm
Maximum Tool Weight: Approx. 6 lbs
Tool Change Time: T-T 0.7 sec. / C-C 2.1 sec.

General:
Machine Weight (Approx.): 9,259 lbs
Machine Dimensions (Approx.): 1,500 mm W × 2,700 mm L
Power Requirement: 11 kVA
Air Pressure Requirement: 87 PSI

Categories	CNC Vertical Machining Centers
Make	Akira Seiki
Model	RMV500APC

AKIRA Mi645 CNC Control
2-Pallet Automatic Pallet Changer
24+1 Tool Capacity
Servo Tool Magazine
Chip Conveyor
Coolant System
Full Enclosure
Automatic Lubrication
Tool Measurement Capability
Pallet Positioning System
