*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Clausing |
| Model: | CKE6156Z/1500 |
| Year: | 2006 |
| Machine Type: | CNC Flat-Bed Lathe |
| Equipped With: |
|---|
| Fagor CNC Control |
| 12″ 3-Jaw Chuck |
| 4-Station Power Turret |
| Aloris Tool Post |
| Steady Rest |
| MistAway Mist Collector |
| Enclosed Work Area |
| Hydraulic / Powered Tailstock |
| Coolant System |
| Chip Tray |
| Machine Lighting |
| Capacity: |
|---|
| Swing Over Bed: 22″ |
| Swing Over Cross Slide: 13″ |
| Distance Between Centers: 60″ |
| Maximum Turning Length: 59″ |
| Chuck Size: 12″ |
| Spindle Bore: 3.23″ |
| Bed Width: 15.75″ |
| Travels: |
|---|
| X-Axis Travel: 12.0″ |
| Z-Axis Travel: 56.3″ |
| X-Axis Rapid Traverse: 236 IPM |
| Z-Axis Rapid Traverse: 394 IPM |
| Spindle: |
|---|
| Spindle Speed Range: 7–2,200 RPM |
| Spindle Speeds: 3 Ranges |
| Spindle Nose: D8 |
| Spindle Bore: 3.23″ |
| Spindle Bore Taper: 1:20 |
| Spindle Motor: 10 HP |
| Turret: |
|---|
| Turret Type: Power Turret |
| Tool Capacity: 4 Stations |
| Tailstock: |
|---|
| Hydraulic / Powered Tailstock |
| Quill Diameter: 2.95″ |
| Quill Travel: 5.91″ |
| Tailstock Taper: MT-5 |
| General: |
|---|
| Power Source: 230/460V / 3-Phase / 60 Hz |
| Machine Dimensions (Approx.): 151″ L × 69″ W × 64″ H |
| Machine Weight (Approx.): 5,700–6,300 lbs. |
