*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | DMG MORI |
| Model No.: | CMX 1100V |
| Year: | 2019 |
| Machine Type: | CNC Vertical Machining Center |
| Control: | Fanuc (F0IMF) CNC Control |
| Country of Origin: | USA |
| Features: |
|---|
| Fanuc F0IMF CNC Control |
| 15,000 RPM High-Speed Spindle |
| 30 Station Automatic Tool Changer |
| CAT 40 Spindle Taper |
| Chip Conveyor (Left Discharge, Scraper Type with Drum Filter) |
| Mist Collector |
| Through-Spindle Coolant Ready |
| Shower Coolant System |
| Renishaw Probe System (Tool Setter & Workpiece Probe) |
| Manual Pulse Generator (MPG) |
| Ethernet/IP Interface |
| Signal Lamp (4 Color) |
| AI Contour Control II |
| Program Storage: 2MB / 1,000 Programs |
| Tool Magazine Door |
| Preparation for Through-Spindle Coolant |
| Capacity: |
|---|
| Max Workpiece Length: 55.1″ |
| Max Workpiece Width: 22″ |
| Max Workpiece Height: 24.8″ |
| Max Workpiece Weight: 2,204.6 lbs |
| Travels: |
|---|
| X Axis Travel: 43.3″ |
| Y Axis Travel: 22″ |
| Z Axis Travel: 20.1″ |
| Spindle: |
|---|
| Spindle Taper: CAT 40 (7/24 Taper) |
| Spindle Speed: 15,000 RPM |
| Spindle Type: High-Speed |
| Tool Changer: |
|---|
| Tool Capacity: 30 ATC |
| Tool Type: Automatic Tool Changer |
| Coolant / Chip Management: |
|---|
| Coolant Type: Water-Soluble |
| Chip Conveyor: Included |
| Through-Spindle Coolant: Ready |
| General: |
|---|
| Power Requirement: 220V / 3-Phase |
| Machine Weight: Approx. 12,000 lbs |
| Overall Dimensions: Approx. 110″ x 95″ x 105″ High |
