DMG Mori NHX 4000 4-Axis CNC Horizontal Machining Center – 2017
Out of stock
| SKU: | 11238 |
| Make/Model: | DMG Mori NHX 4000 |
| Year: | 2017 |
| Condition: | Used – Good |
| Video: | On Request |
Add to WishlistRemove from Wishlist
Add to Wishlist
*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | DMG Mori |
| Model No.: | NHX 4000 |
| Year of Manufacture: | 2017 |
| Condition: | Used – Good |
| Machine Type: | CNC Horizontal Machining Center |
| CNC Control: | DMG Mori CELOS Control |
| Equipped With: |
|---|
| DMG Mori CELOS Control (MAPPS V / ERGOline Interface) |
| Built-In 4th Axis (Rotary Pallet) |
| Twin Pallet Changer (APC) |
| 15,000 RPM High-Speed Spindle |
| BT40 / CAT 40 Spindle Taper |
| 60 Station Tool Magazine |
| Chip Conveyor |
| Coolant System |
| Through Spindle Coolant (Optional / Common) |
| Renishaw Probe (Optional) |
| Tool Setter (Optional) |
| USB / Ethernet Interface |
| Fully Enclosed Guarding |
| Automatic Tool Changer |
| Linear Guideways |
| Capacity: |
|---|
| Pallet Size: 15.7″ × 15.7″ (400 mm × 400 mm) |
| Max Workpiece Diameter: 24.8″ |
| Max Workpiece Height: 35.4″ |
| Max Table Load: 880 lbs |
| Travels: |
|---|
| X Axis Travel: 22.0″ |
| Y Axis Travel: 22.0″ |
| Z Axis Travel: 26.0″ |
| Rapid Traverse (X/Y/Z): ~2,362 IPM |
| Spindle: |
|---|
| Spindle Taper: BT40 / CAT 40 |
| Spindle Speed: 15,000 RPM |
| Spindle Motor: 30 HP (Approx.) |
| Tooling System: |
|---|
| Tool Magazine Capacity: 60 Tools |
| ATC Type: Arm Type Automatic Tool Changer |
| Pallet System: |
|---|
| Type: Twin Pallet Automatic Pallet Changer (APC) |
| Pallet Indexing: 0.001° |
| General: |
|---|
| Power Requirement: 220V / 3-Phase / 60 Hz |
| Machine Weight: ~18,000 lbs |
| Features: |
|---|
| High-Speed Horizontal Machining for Maximum Productivity |
| 4-Axis Capability with Full Rotary Indexing |
| Twin Pallet System for Continuous Production |
| CELOS Control with Modern Touch Interface |
| Excellent Chip Evacuation for Heavy Cutting |
| High Rigidity Structure for Accuracy & Stability |
| Fast Tool Change & High Rapid Rates |
| Ideal for Automotive, Aerospace & Production Machining |
| Reduced Idle Time with Pallet Changer |
| Automation Ready (FMS / Robotic Integration) |
| Categories | CNC Horizontal Machining Center |
|---|---|
| Make | |
| Model | NHX 4000 |
