*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model No.: | TL-2 |
| Year of Manufacture: | 2016 |
| Condition: | Used – Good |
| Machine Type: | CNC Toolroom Lathe |
| CNC Control: | Haas CNC Control |
| Country of Origin: | USA |
| Equipped With: |
|---|
| Haas CNC Control |
| Manual & CNC Operation Modes |
| 10″ 3-Jaw Chuck |
| Quick Change Tool Post |
| Coolant System |
| Chip Tray |
| Work Light |
| Capacity: |
|---|
| Max Swing Over Bed: 16″ |
| Max Turning Length: 48″ |
| Max Turning Diameter: 8″ |
| Travels: |
|---|
| X-Axis Travel: 8″ |
| Z-Axis Travel: 30″ |
| Spindle: |
|---|
| Spindle Speed: 3,600 RPM |
| Spindle Bore: 3″ |
| Spindle Motor: 10 HP |
| Tooling: |
|---|
| Tool Post Type: Quick Change Tool Post |
| General: |
|---|
| Power Source: AC 220 V, 3-Phase, 50/60 Hz |
| Machine Dimensions (L x W x H): 120″ x 65″ x 75″ |
| Machine Weight: 4,500 lbs Approx. |
