*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Mazak |
| Model: | VCN 510C-II |
| Year: | 2008 |
| Condition: | Used |
| Machine Type: | CNC Vertical Machining Center |
| CNC Control: | Mazatrol Matrix Nexus |
| Cutting Time: | 11,000 Hours |
| Features: |
|---|
| Mazatrol Matrix Nexus CNC Control |
| 12,000 RPM High-Speed Spindle |
| CAT 40 Spindle Taper |
| 25 HP Spindle Motor |
| 30-Tool Automatic Tool Changer (ATC) |
| Tool Length Probe |
| Automatic Tool Changer Carousel |
| Coolant System |
| Chip Conveyor / Chip Removal System |
| Fully Enclosed Machining Area |
| Table: |
|---|
| Table Length: 51.18″ |
| Table Width: 21.65″ |
| Table Size: 51.18″ × 21.65″ |
| Maximum Table Load Capacity: 2,646 lbs. |
| Number of T-Slots: 5 |
| T-Slot Width: 5/8″ |
| Travels: |
|---|
| X-Axis Travel: 41.3″ |
| Y-Axis Travel: 20″ |
| Z-Axis Travel: 20″ |
| Rapid Traverse Rate (X/Y/Z): 1,417 IPM |
| Spindle Nose to Table Distance: 5.9″–26″ |
| Spindle: |
|---|
| Spindle Speed: 12,000 RPM |
| Spindle Taper: CAT 40 |
| Spindle Motor Power: 25 HP |
| Automatic Tool Changer: |
|---|
| Tool Changer Capacity: 30 Tools |
| Tool Changer Type: Side-Mounted |
| Maximum Tool Diameter: 3.15″ |
| Maximum Tool Length: 13.78″ |
| Maximum Tool Weight: 13.78 lbs. |
| General: |
|---|
| Overall Dimensions (Approx.): 120″ L × 112″ W × 114″ H |
| Machine Weight (Approx.): 15,200 lbs. |
