Used Reishauer RZ 150 CNC Gear Grinder - Siemens 840D, 150mm Capacity

Reishauer RZ 150 CNC Gear Grinder – Siemens 840D, 150mm Capacity

SKU 11366

Make/Model Reishauer RZ 150

Year 2006

Video On Request

Out of stock

SKU:	11366
Make/Model:	Reishauer RZ 150
Year:	2006
Video:	On Request

SKU: 11366

*All specifications are approximations and are subject to verification. Comes as shown in the images.
Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	Reishauer
Model No.:	RZ 150
Year of Manufacture:	2006
Machine Type:	CNC Gear Grinding Machine
CNC Control:	Siemens Sinumerik 840D
Country of Origin:	Switzerland

Equipped With:
Siemens Sinumerik 840D CNC Control
High-Speed Gear Grinding System
Automatic Grinding Cycles
Balance System
Coolant & Filtration System
Dust/Mist Extraction
Full Enclosure

Capacity:
Workpiece Diameter: 10 – 150 mm
Module Range: 1 – 3
Max Face Width: 100 mm
Max Shaft Length: 490 mm
Helix Angle: ±40°

Spindle:
Max Grinding Speed: 80 m/s

General:
Power: 480V, 3-Phase, 60 Hz
Overall Dimensions: Approx. 120″ x 90″ x 95″ High
Weight: Approx. 18,000 lbs

Equipped With:
Siemens Sinumerik 840D CNC Control
High-Speed Gear Grinding System
Automatic Grinding Cycles
Balance System
Coolant & Filtration System
Dust/Mist Extraction
Full Enclosure

Capacity:
Workpiece Diameter: 10 – 150 mm
Module Range: 1 – 3
Max Face Width: 100 mm
Max Shaft Length: 490 mm
Helix Angle: ±40°

Spindle:
Max Grinding Speed: 80 m/s

General:
Power: 480V, 3-Phase, 60 Hz
Overall Dimensions: Approx. 3,048 mm x 2,286 mm x 2,413 mm High
Weight: Approx. 18,000 lbs
