*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Takamaz |
| Model: | XC-100 |
| Year: | 2012 |
| Equipped With: |
|---|
| Fanuc Series 0i-TD CNC Control |
| Integrated Gantry Loader |
| Automated Workpiece Loading System |
| 6″ 3-Jaw Hydraulic Chuck |
| 8-Station Turret |
| Parts Catcher / Parts Handling System |
| Chip Conveyor |
| Coolant System |
| Hydraulic System |
| Fully Enclosed Work Area |
| Capacity: |
|---|
| Maximum Turning Diameter: 7.08″ |
| Maximum Turning Length: 7.48″ |
| Chuck Size: 6″ |
| Travels: |
|---|
| X-Axis Travel: 4.72″ |
| Z-Axis Travel: 9.055″ |
| Spindle: |
|---|
| Chuck Type: 3-Jaw Hydraulic Chuck |
| Chuck Size: 6″ |
| Turret: |
|---|
| Turret Capacity: 8 Stations |
| General: |
|---|
| Country of Manufacture: Japan |
| Machine Dimensions (Approx.): 55″ × 59″ × 75″ |
| Machine Weight (Approx.): 4,630 lbs |
