Walter Helitronic Power HMC-400 5 Axis CNC Grinder

All specifications are approximations and are subject to verification.

SKU	2155
Make	Walter
Model No.	HMC 400
Year	1995
Serial #	6026
Condition	Good Working

Equipped With:
CYLINDRICAL TOOLS (END MILLS) Program
TAPERED TOOLS (END MILLS) Program
STEP DRILLS Program
STEP TOOLS Program
SIDE MILLING CUTTERS Program
WOODWORKING TOOLS Program
PROFILE Program
TAPS Program
CRESTCUT Program
WARM UP PROGRAM
CYLINDRICAL GRINDING Program
10,500 RPM Precision Spindle
Windows based Walter cnc Control
CBN Diamond Wheel installed
Probing sytem
Smog Hog Mist Collector
Centrifuge and Coolant Tank
Full Enclosure

Specifications:
Capacity of Workpiece Dia.: 0.04″ – 3.9″
Max. Peripheral Grinding: 10″
Max. End Face Grinding: 7.3″
Max. X Axis Travel: 13.8″
Max. Y Axis Travel: 7.9″
Max. Z Axis Travel: 18.5″
A Axis: Infinite
C Axis Rotary: +/- 200° ( 0.001° )
Grinding Spindle Motor: 16 hp
Grinding Wheel Type: Diamond or CBN Grinding
Wheel Dia. Max.: 5.9″
Grinding Wheel Speed: 500 to 10,500 RPM

General:
Air Required: 6 bar
Total Power Requirement Max: 18kw
Power: 460v / 60hz
Overall Dimensions: 85.8″ x 63″ x 86.6″ High Weight: 7055 lbs
