*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Warner & Swasey |
| Model: | M-5450 |
| Machine Type: | CNC Turning Machine |
| CNC Control: | FANUC CNC |
| Equipped With: |
|---|
| FANUC CNC Control |
| WSC-8 Control |
| 8″ 3-Jaw Hydraulic Chuck |
| 10-Station Turret |
| 20 HP AC Main Spindle Motor |
| Turbo Motorized Chip Conveyor |
| Coolant System |
| Turret Coolant Distributor |
| Central Lubrication System |
| Swing-Up Tailstock |
| Manual & Machine Documentation |
| Tooling |
| Spare Parts |
| Additional Spare Control |
| Capacity: |
|---|
| Chuck Size: 8″ |
| Chuck Type: 3-Jaw Hydraulic Hi-Lo Chuck |
| Bar Capacity: 2″ |
| Spindle Through-Hole: 2.56″ |
| Spindle Nose: A2-6 |
| Maximum Turning Length: 11″ |
| Travels: |
|---|
| Longitudinal Travel: 7″ |
| Cross Travel: 5.25″ |
| Rapid Traverse X-Axis: 400 IPM |
| Rapid Traverse Z-Axis: 400 IPM |
| Spindle: |
|---|
| Spindle Speed Range: 55–4,000 RPM |
| Maximum Spindle Speed: 4,000 RPM |
| Spindle Motor: 20 HP AC |
| Spindle Nose: A2-6 |
| Turret: |
|---|
| Turret Type: CNC Turret |
| Number of Tool Stations: 10 |
| General: |
|---|
| Machine Dimensions (Approx.): 90″ L × 77″ D × 66″ H |
| Machine Weight (Approx.): 10,500 lbs. |
