Yama Seiki GTZ-2600Y CNC Twin Spindle Twin Turret Turning Center
SKU
11590
Make/Model
Yama Seiki GTZ-2600Y
Year
2015
Condition
Used - Good
Video
On Request
Out of stock
| SKU: | 11590 |
| Make/Model: | Yama Seiki GTZ-2600Y |
| Year: | 2015 |
| Condition: | Used – Good |
| Video: | On Request |
Add to WishlistRemove from Wishlist
Add to Wishlist
*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Yama Seiki |
| Model: | GTZ-2600Y |
| Year: | 2015 |
| Condition: | Used – Good |
| Machine Type: | CNC Twin Spindle Twin Turret Turning Center |
| Control: | Fanuc 32i CNC Control |
| Equipped With: |
|---|
| Fanuc 32i CNC Control |
| Twin Opposing Spindles |
| Twin 10-Station Turrets |
| Y-Axis |
| Live Tooling |
| Live Milling |
| C-Axis Main Spindle |
| C-Axis Sub Spindle |
| (1) 8″ 4-Jaw Chuck |
| (1) 8″ Collet Chuck |
| Automatic Parts Catcher |
| Coolant System |
| Full Enclosure |
| Work Light |
| Capacity: |
|---|
| Max Cutting Diameter: 9.84″ |
| Max Cutting Length: 23.3″ |
| Spindle Bore: 3″ |
| Main Spindle: |
|---|
| Maximum Cutting Diameter: 9.84″ |
| Maximum Cutting Length: 23.3″ |
| Spindle Bore: 3.00″ |
| Main Chuck: 8″ 4-Jaw Chuck |
| Main Spindle Speed: Approx. 4,000 RPM |
| Sub Spindle: |
|---|
| Sub Chuck: 8″ Collet Chuck |
| Sub Spindle Speed: 4,000 RPM |
| Opposing Sub Spindle |
| Live Tooling: |
|---|
| Live Milling Equipped |
| Maximum Live Tool Speed: 6,000 RPM |
| Turrets: |
|---|
| Upper Turret: 10 Stations |
| Lower Turret: 10 Stations |
| Total Tool Stations: 20 |
| General: |
|---|
| Country of Origin: Taiwan |
| Power: 220v/ 60 Hz/ 3 Phase/ 65 kVA |
| Main Power Switch: 160 A |
| Machine Weight: Approx. 19,842 lbs. |
| Equipped With: |
|---|
| Fanuc 32i CNC Control |
| Twin Opposing Spindles |
| Twin 10-Station Turrets |
| Y-Axis |
| Live Tooling |
| Live Milling |
| C-Axis Main Spindle |
| C-Axis Sub Spindle |
| (1) 203 mm 4-Jaw Chuck |
| (1) 203 mm Collet Chuck |
| Automatic Parts Catcher |
| Coolant System |
| Full Enclosure |
| Work Light |
| Capacity: |
|---|
| Max Cutting Diameter: 250 mm |
| Max Cutting Length: 592 mm |
| Spindle Bore: 76 mm |
| Main Spindle: |
|---|
| Maximum Cutting Diameter: 250 mm |
| Maximum Cutting Length: 592 mm |
| Spindle Bore: 76 mm |
| Main Chuck: 203 mm 4-Jaw Chuck |
| Main Spindle Speed: Approx. 4,000 RPM |
| Sub Spindle: |
|---|
| Sub Chuck: 203 mm Collet Chuck |
| Sub Spindle Speed: 4,000 RPM |
| Opposing Sub Spindle |
| Live Tooling: |
|---|
| Live Milling Equipped |
| Maximum Live Tool Speed: 6,000 RPM |
| Turrets: |
|---|
| Upper Turret: 10 Stations |
| Lower Turret: 10 Stations |
| Total Tool Stations: 20 |
| General: |
|---|
| Country of Origin: Taiwan |
| Power: 220v/ 60 Hz/ 3 Phase/ 65 kVA |
| Main Power Switch: 160 A |
| Machine Weight: Approx. 19,842 lbs. |
| Categories | CNC Lathes & Turning Centers |
|---|---|
| Make | Yama Seiki |
| Model | GTZ-2600Y |
