*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Hwacheon |
| Model: | Vesta 1000+ |
| Year: | 2021 |
| Condition: | Used – Good |
| Machine Type: | CNC Vertical Machining Center |
| Control: | Fanuc Oi-MF Plus CNC Control |
| Equipped With: |
|---|
| Fanuc Oi-MF Plus CNC Control |
| 12,000 RPM High-Speed Spindle |
| 30 Position Automatic Tool Changer |
| BT-40 Spindle Taper |
| Side or Rear-Mounted Swarf Conveyor |
| Spindle Chiller |
| Coolant System |
| Fully Enclosed Splash Guarding |
| Work Light |
| Books & Manuals |
| Capacity: |
|---|
| Table Size: 43.3″ X 19.685″ |
| Maximum Table Load: 1,540 LBS |
| Travels: |
|---|
| X-Axis Travel: 39.3″ |
| Y-Axis Travel: 21.653″ |
| Z-Axis Travel: 19.68″ |
| X-Axis Rapid Traverse Rate: 1,414 IPM |
| Y-Axis Rapid Traverse Rate: 1,414 IPM |
| Z-Axis Rapid Traverse Rate: 1,179 IPM |
| Spindle: |
|---|
| Spindle Speed: 12,000 RPM |
| Spindle Motor: 25 HP |
| Spindle Taper: BT-40 |
| Automatic Tool Changer: |
|---|
| Tool Changer Capacity: 30 ATC |
| General: |
|---|
| Overall Dimensions: 88″ X 97″ X 112″ High Approx. |
| Approximate Weight: 26,000 LBS |
| Power Requirement: 220V / 3-Phase |
| Made In: South Korea |
