*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Hwacheon |
| Model: | Hi-Tech 550B MC |
| Year: | 2020 |
| Equipped With: |
|---|
| Fanuc 0i-TD CNC Control |
| Live Milling / Driven Tooling |
| 18″ 3-Jaw Hydraulic Chuck |
| 12-Station Turret |
| Tailstock |
| Chip Conveyor |
| Coolant System |
| Fully Enclosed Work Area |
| Low Hours |
| Capacity: |
|---|
| Swing Over Bed: 31.5″ |
| Maximum Cutting Diameter: 23.23″ |
| Standard Cutting Diameter: 10.83″ |
| Maximum Cutting Length: 43.31″ |
| Chuck Size: 18″ |
| Travels: |
|---|
| X-Axis Travel: 13.58″ |
| Z-Axis Travel: 45.28″ |
| Spindle: |
|---|
| Spindle Nose: A2-11 |
| Maximum Spindle Speed: 1,800 RPM |
| Spindle Through-Hole Diameter: 5.20″ |
| Turret: |
|---|
| Turret Capacity: 12 Stations |
| Maximum Live Tool Speed: 4,000 RPM |
| Maximum Drill / Tap Size: 1.26″ / M20 |
| Tailstock: |
|---|
| Tailstock: Equipped |
| Electrical: |
|---|
| Rated Voltage: 220 V |
| Phase: 3 Phase |
| Rated Frequency: 60 Hz |
| Electrical Power Supply: 65 kVA |
| General: |
|---|
| Country of Manufacture: Korea |
| Machine Dimensions (Approx.): 195″ L × 92″ W × 96″ H |
| Machine Weight (Approx.): 25,130 lbs |
