*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Brother |
| Model No.: | Speedio S700X1 |
| Year: | 2017 |
| Machine Type: | CNC Vertical Machining Center |
| Control: | Brother CNC Control |
| Country of Origin: | Japan |
| Travels: |
|---|
| X-Axis Travel: 27.6″ |
| Y-Axis Travel: 15.7″ |
| Z-Axis Travel: 11.8″ |
| Spindle: |
|---|
| Spindle Speed: 27,000 RPM |
| Spindle Taper: CAT 30 |
| Spindle Motor: 13.5 HP |
| High-Speed Direct Drive Spindle |
| Tool Changer: |
|---|
| Tool Magazine Capacity: 21 Tools |
| Automatic Tool Changer (ATC) |
| High-Speed Tool Change Design |
| Capacity: |
|---|
| Table Size: Approx. 31.5″ x 15.7″ |
| Max Table Load: Approx. 440 lbs |
| Features: |
|---|
| Nikken 4th/5th Axis Rotary Table |
| LNS Chip Conveyor |
| High-Speed Tapping Capability |
| Rigid Tapping |
| High Acceleration / Fast Cycle Times |
| Compact Footprint |
| Flood Coolant System |
| Full Enclosure |
| Ethernet Interface |
| USB Interface |
| General: |
|---|
| Power Requirement: 220V / 3-Phase |
| Machine Weight: Approx. 4,500 – 5,500 lbs |
| Overall Dimensions: Approx. 65″ x 75″ x 90″ High |
