Daewoo ACE-V35 CNC Vertical Machining Center

SKU 11806
Make/Model Daewoo ACE-V35
Year 1994
Video On Request
Out of stock
SKU: 11806
Make/Model: Daewoo ACE-V35
Year: 1994
Video: On Request
SKU: 11806

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make: Daewoo
Model: ACE-V35
Year: 1994
Machine Type: CNC Vertical Machining Center
Control: Fanuc O-M CNC Control
Features:
Fanuc O-M CNC Control
16-Tool Automatic Tool Changer
(2) Rotating Pallet System
Chip Conveyor
Coolant System
Rigid Tapping
Full Enclosure / Splash Guarding
Work Light
Manual Pulse Generator
RS-232 Port
Travels:
X-Axis Travel: 22″
Y-Axis Travel: 15.7″
Z-Axis Travel: 18.1″
Spindle Nose to Table Top: 6.7″ – 24.8″
Rapid Traverse: 787 IPM
Table:
Table Size: 17.7″ × 25.6″
Number of Pallets: 2
Pallet Load Capacity: 661 lbs.
Spindle:
Spindle Speed Range: 60–6,000 RPM
Maximum Spindle Speed: 6,000 RPM
Spindle Taper: CAT 40
Spindle Motor: 10 HP
Automatic Tool Changer:
ATC Capacity: 16 Tools
Tool Taper: CAT 40
Tool Change Positions: 16
Feedrate:
Cutting Feed Rate: 0.01–315 IPM
Rapid Traverse Rate: 787 IPM
General:
Power Source: 220V / 3-Phase / 60 Hz
Machine Dimensions (Approx.): 126″ L × 94″ W × 114″ H
Machine Weight (Approx.): 13,000 lbs.
Travels:
X-Axis Travel: 559 mm
Y-Axis Travel: 399 mm
Z-Axis Travel: 460 mm
Spindle Nose to Table Top: 170 mm – 630 mm
Rapid Traverse: 787 IPM
Table:
Table Size: 450 mm × 650 mm
Number of Pallets: 2
Pallet Load Capacity: 661 lbs.
Spindle:
Spindle Speed Range: 60–6,000 RPM
Maximum Spindle Speed: 6,000 RPM
Spindle Taper: CAT 40
Spindle Motor: 10 HP
Automatic Tool Changer:
ATC Capacity: 16 Tools
Tool Taper: CAT 40
Tool Change Positions: 16
Feedrate:
Cutting Feed Rate: 0.01–315 IPM
Rapid Traverse Rate: 787 IPM
General:
Power Source: 220V / 3-Phase / 60 Hz
Machine Dimensions (Approx.): 3,200 mm L × 2,388 mm W × 2,896 mm H
Machine Weight (Approx.): 13,000 lbs.
CategoriesCNC Vertical Machining Centers
MakeDAEWOO
ModelACE-V35
  • Fanuc O-M CNC Control
  • 16-Tool Automatic Tool Changer
  • (2) Rotating Pallet System
  • Chip Conveyor
  • Coolant System
  • Rigid Tapping
  • Full Enclosure / Splash Guarding
  • Work Light
  • Manual Pulse Generator
  • RS-232 Port
Daewoo ACE V35 (2)Daewoo ACE V35 (3)Daewoo ACE V35 (4)
