*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Daewoo |
| Model: | PUMA 400 |
| Year: | 1998 |
| Machine Type: | CNC Turning Center |
| CNC Control: | Fanuc Series 18-T |
| Equipped With: |
|---|
| Fanuc Series 18-T CNC Control |
| 10-Station Turret |
| 15″ 3-Jaw Hydraulic Power Chuck |
| Hydraulic Tailstock |
| Tool Presetter |
| Chip Conveyor |
| Coolant System |
| Fully Enclosed Work Area |
| Capacity: |
|---|
| Maximum Swing Over Bed: 27.5″ |
| Maximum Turning Diameter: 21.7″ |
| Maximum Turning Length: 41.1″ |
| Swing Over Carriage: 18.9″ |
| Maximum Bar Capacity: 4.6″ |
| Travels: |
|---|
| X-Axis Travel: 14.3″ |
| Z-Axis Travel: 43.5″ |
| X-Axis Rapid Traverse: 630 IPM |
| Z-Axis Rapid Traverse: 790 IPM |
| Spindle: |
|---|
| Spindle Motor Power: 50 HP |
| Spindle Speed: 2,000 RPM |
| Spindle Nose: A2-11 |
| Spindle Bore: 5.2″ |
| Chuck Size: 15″ |
| Chuck Type: 3-Jaw Hydraulic Chuck |
| Turret: |
|---|
| Turret Capacity: 10 Stations |
| Tailstock: |
|---|
| Tailstock Type: Hydraulic |
| Tailstock Quill Taper: MT-6 |
| Electrical: |
|---|
| Electrical Supply: Approx. 200–220V |
| Phase: 3-Phase |
| Frequency: 50–60 Hz |
| General: |
|---|
| Machine Weight (Approx.): 21,200 lbs |
