Daewoo Puma 200C CNC Turning Center

SKU 11804
Make/Model Daewoo Puma 200C
Year 1996
Video On Request
Out of stock
SKU: 11804
Make/Model: Daewoo Puma 200C
Year: 1996
Video: On Request
SKU: 11804

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make: Daewoo
Model: Puma 200C
Year: 1997
Machine Type: CNC Lathe
Control: Fanuc 18-T
Equipped With:
Fanuc 18-T CNC Control
8″ 3-Jaw Hydraulic Chuck
12 Station Automatic Turret
Tailstock
Parts Catcher
Chip Conveyor
Tool Presetter
Coolant System
RS-232 Ports
Capacity:
Max. Turning Diameter: 13.78″
Max. Turning Length: 15.75″
Max. Bar Capacity: 2.56″
Swing Over Bed: 20.08″
Swing Over Saddle: 12.99″
Travels:
X-Axis Travel: 9.53″
Z-Axis Travel: 17.32″
Rapid Traverse X-Axis: 787 IPM
Rapid Traverse Z-Axis: 1,000 IPM
Spindle:
Spindle Nose: A2-6
Spindle Bore: 2.99″
Spindle Speed: 45–4,500 RPM
Spindle Motor: 15/20 HP
Turret:
Turret Capacity: 12 Stations
Turret Index Time: 0.5 Second
Tailstock:
Tailstock Taper: MT-4
Tailstock Quill Diameter: 2.95″
Tailstock Quill Travel: 3.15″
General:
Power Source: 220v / 3-Phase / 50/60 Hz
Overall Dimensions (Approx.): 105″ × 64″ × 69″
Machine Weight (Approx.): 8,800 lbs.
Equipped With:
Fanuc 18-T CNC Control
203 mm 3-Jaw Hydraulic Chuck
12 Station Automatic Turret
Tailstock
Parts Catcher
Chip Conveyor
Tool Presetter
Coolant System
RS-232 Ports
Capacity:
Max. Turning Diameter: 350 mm
Max. Turning Length: 400 mm
Max. Bar Capacity: 65 mm
Swing Over Bed: 510 mm
Swing Over Saddle: 330 mm
Travels:
X-Axis Travel: 242 mm
Z-Axis Travel: 440 mm
Rapid Traverse X-Axis: 787 IPM
Rapid Traverse Z-Axis: 1,000 IPM
Spindle:
Spindle Nose: A2-6
Spindle Bore: 76 mm
Spindle Speed: 45–4,500 RPM
Spindle Motor: 15/20 HP
Turret:
Turret Capacity: 12 Stations
Turret Index Time: 0.5 Second
Tailstock:
Tailstock Taper: MT-4
Tailstock Quill Diameter: 75 mm
Tailstock Quill Travel: 80 mm
General:
Power Source: 220v / 3-Phase / 50/60 Hz
Overall Dimensions (Approx.): 2,667 mm × 1,626 mm × 1,753 mm
Machine Weight (Approx.): 8,800 lbs.
