*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Doosan |
| Model: | HP 4000 |
| Year: | 2013 |
| Features: |
|---|
| Fanuc Series 31i-A CNC Control |
| 4-Axis Horizontal Machining Center |
| 2-Pallet Automatic Pallet Changer |
| (2) 15.75″ x 15.75″ Pallets |
| 40 Position Automatic Tool Changer |
| CAT 40 Spindle |
| 35 HP Spindle |
| 14,000 RPM High-Speed Spindle |
| Through-Spindle Coolant |
| LNS Turbo HB Chip Conveyor |
| 1° Pallet Indexing |
| CAPACITY: |
|---|
| Pallet Size: 15.75″ x 15.75″ |
| X-Axis Travel: 23.6″ |
| Y-Axis Travel: 22.0″ |
| Z-Axis Travel: 23.6″ |
| Maximum Table Load: 882 lbs. |
| Pallet Indexing: 1° |
| SPINDLE: |
|---|
| Spindle Speed: 14,000 RPM |
| Spindle Motor: 35 HP |
| Spindle Taper: CAT 40 |
| Feed Rate: 1,187 IPM |
| Through-Spindle Coolant |
| Automatic TOOL CHANGER: |
|---|
| 40 Position Automatic Tool Changer |
| Automatic Tool Changer (ATC) |
| CAT 40 Tool Interface |
| GENERAL: |
|---|
| 4th Axis Integrated Rotary Pallet System |
| Power Requirement: 200/220V / 3 Phase / 50 Hz |
| Cutting Time: 7,654 Hours |
