*All specifications are approximations and are subject to verification. Comes as shown in the images. Please call us with any questions before purchasing. All sales are final.*
| Make: |
Haas |
| Model: |
Mini Mill CE |
| Year: |
2000 |
| Machine Type: |
CNC Vertical Machining Center |
| CNC Control: |
Haas CNC Control |
Haas Vector Spindle Drive
| Features: |
| Haas CNC Control |
| 10-Station Automatic Tool Changer |
| Carousel Tool Changer |
| Coolant System |
| Rigid Tapping |
| Enclosed Work Area |
| Spindle Load Meter |
| Automatic Lubrication |
| Quick Code Programming |
| CE Configuration |
| Table: |
| Table Size: 36″ × 12″ |
| T-Slots: 3 |
| Maximum Table Load: 500 lbs. |
| Travels: |
| X-Axis Travel: 16″ |
| Y-Axis Travel: 12″ |
| Z-Axis Travel: 10″ |
| Spindle Nose to Table: 4″–14″ |
| Rapid Traverse: 600 IPM |
| Maximum Cutting Feed: 500 IPM |
| Spindle: |
| Spindle Motor: 7.5 HP |
| Maximum Spindle Speed: 6,000 RPM |
| Spindle Taper: CAT 40 |
| Automatic Tool Changer: |
| Type: Carousel |
| Tool Capacity: 10 Stations |
| Maximum Tool Diameter: 3.5″ |
| Maximum Tool Weight: 12 lbs. |
| Tool-to-Tool Time: 3.6–4.2 sec. |
| General: |
| Power Source: 208–240V / 3-Phase / 50/60 Hz |
| Machine Weight (Approx.): 4,000 lbs. |
| Machine Dimensions (Approx.): 84″ L × 60.3″ W × 102″ H |
