*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model: | TM-2 |
| Year: | 2005 |
| Machine Type: | CNC Toolroom Mill |
| CNC Control: | HAAS CNC Control |
| Equipped With: |
|---|
| HAAS CNC Control |
| HAAS Vector Drive |
| Quick Code Programming |
| Intuitive Programming System (IPS) |
| 20-Station Automatic Tool Changer |
| BT-40 Taper Spindle |
| 4,000 RPM Spindle |
| 7.5 HP Spindle Motor |
| Rigid Tapping |
| Remote / Manual Pulse Generator Handwheel |
| Coolant System |
| Chip Management |
| Enclosed Work Area |
| Worktable with T-Slots |
| Table: |
|---|
| Table Size: 57.75″ × 10.5″ |
| T-Slot Width: 0.626″–0.630″ |
| T-Slot Center Distance: 4.00″ |
| Number of T-Slots: 3 |
| Maximum Table Load: 1,000 lbs. |
| Travels: |
|---|
| X-Axis Travel: 40.00″ |
| Y-Axis Travel: 16.00″ |
| Z-Axis Travel: 16.00″ |
| Spindle Nose to Table: 4.00″–20.00″ |
| Spindle: |
|---|
| Spindle Taper: BT-40 |
| Spindle Speed: 0–4,000 RPM |
| Spindle Motor: 7.5 HP |
| Maximum Torque: 33 ft-lb @ 1,200 RPM |
| Automatic Tool Changer: |
|---|
| Tool Changer Type: Automatic Tool Changer |
| Tool Capacity: 20 Stations |
| Tool Taper: BT-40 |
| Feedrates: |
|---|
| Rapid Traverse X/Y/Z: 200 IPM |
| Maximum Cutting Feed: 200 IPM |
| General: |
|---|
| Power Source: 208 / 240V / 3-Phase / 50/60 Hz |
| Machine Weight (Approx.): 4,000 lbs. |
| Overall Footprint (Approx.): 85″ L × 75″ W × 100″ H |
