*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Haas |
| Model No.: | VF-3 |
| Year: | 2019 |
| Condition: | Used |
| Machine Type: | CNC Vertical Machining Center |
| Control: | Haas CNC Control |
| Country of Origin: | USA |
| Features: |
|---|
| Haas CNC Control |
| 4th Axis Rotary Table |
| Tailstock |
| Programmable Coolant |
| Side Mount Tool Changer |
| High Speed Spindle |
| Rigid Tapping |
| Flood Coolant System |
| Chip Auger |
| USB Port |
| Electronic Handwheel |
| Work Light |
| Way Covers |
| Automatic Lubrication System |
| Full Enclosure |
| Travels: |
|---|
| X-Axis Travel: 40″ |
| Y-Axis Travel: 20″ |
| Z-Axis Travel: 25″ |
| Table: |
|---|
| Table Size: 48″ x 18″ |
| Maximum Table Load: 3,500 lbs |
| T-Slot Width: 5/8″ |
| Number of T-Slots: 5 |
| Spindle: |
|---|
| Spindle Speed: 8,100 RPM |
| Spindle Taper: CAT 40 |
| Spindle Motor: 30 HP |
| Tool Changer: |
|---|
| Tool Capacity: 20 Position Side Mount ATC |
| Maximum Tool Diameter: 5″ |
| Maximum Tool Weight: 12 lbs |
| Feeds: |
|---|
| Rapid Traverse Rate: 1,000 IPM |
| Cutting Feed Rate: 650 IPM |
| General: |
|---|
| Power Requirement: 220V / 3 Phase |
| Machine Weight: Approx. 12,500 lbs |
| Machine Dimensions: Approx. 130″ x 105″ x 110″ |
