*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Methods |
| Model: | KMH-300A-F004 |
| Year: | 2015 |
| Features: |
|---|
| Fanuc Series 0i-MD CNC Control |
| 2-Pallet Automatic Pallet Changer (APC) |
| Full 4th Axis Rotary Table |
| 30-Station Automatic Tool Changer |
| 12,000 RPM Spindle |
| CAT 40 Spindle |
| Chip Conveyor |
| Coolant System |
| Rigid Tapping |
| Electronic Handwheel |
| Automatic Lubrication |
| Work Light |
| Pallet: |
|---|
| Number of Pallets: 2 |
| Pallet Size: 12.6″ × 12.6″ |
| Maximum Pallet Load:. 660 lbs |
| Travels: |
|---|
| X-Axis Travel: 20″ |
| Y-Axis Travel: 20″ |
| Z-Axis Travel: 20″ |
| Feed Rates: |
|---|
| Rapid Traverse (X/Y/Z): 2,362 IPM |
| Cutting Feedrate: Programmable |
| Spindle: |
|---|
| Spindle Speed: 12,000 RPM |
| Spindle Taper: CAT 40 |
| Spindle Motor: Approx. 20 HP |
| Spindle Type: Direct Drive |
| Automatic Tool Changer: |
|---|
| Tool Capacity: 30 Stations |
| Tool Changer Type: Automatic Tool Changer |
| Max Tool Diameter: 3.1″ |
| Max Tool Length: 11.8″ |
| Max Tool Weight: 15.4 lbs |
| Electrical: |
|---|
| Power Requirement: 220 Volt |
| Phase: 3 Phase |
| Frequency: 60 Hz |
| General: |
|---|
| Machine Dimensions (Approx.): 118″ × 95″ × 108″ |
| Machine Weight (Approx.): 17,500 lbs |
