*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Feeler |
| Model: | FT-250MC |
| Year: | 2012 |
| Machine Type: | CNC Milling & Turning Center |
| CNC Control: | Fanuc Oi-TD |
| Equipped With: |
|---|
| Live Tooling: (1) Live Tool Holder |
| Tool Presetter: Included |
| Chip Management: Chip Conveyor |
| Parts Handling: Parts Conveyor |
| Coolant System: Included |
| Workholding: 5C Collet Chuck |
| Capacity: |
|---|
| Max. Turning Diameter: 16.5″ |
| Max. Turning Length: 42.5″ |
| Bar Capacity: 3.0″ |
| Chuck Diameter: 10″ |
| Swing Over Bed: 25″ |
| Travels: |
|---|
| X-Axis Travel: 9.05″ |
| Z-Axis Travel: 44.09″ |
| Rapid Traverse – X: 944 IPM |
| Rapid Traverse – Z: 944 IPM |
| Spindle: |
|---|
| Spindle Speed: Up to 3,500 RPM |
| Spindle Nose: A2-8 |
| Spindle Hole: 3.46″ |
| Spindle Bearing Inner Diameter: 5.11″ |
| Spindle Motor: 30 HP |
| Turret: |
|---|
| Turret Type: BMT65 |
| Turret Positions: 12 Stations |
| Live Tooling: Included |
| Live Tool Holder: (1) |
| General: |
|---|
| Cutting Time: 7,550 Hours |
| Machine Weight (Approx.): 15,400 lbs. |
| Machine Dimensions (Approx.): 167″ L × 87″ W × 82″ H |
