Leadwell MV-50i CNC Vertical Machining Center

SKU 11868

Make/Model Leadwell MV-50i

Year 2007

Out of stock

SKU:	11868
Make/Model:	Leadwell MV-50i
Year:	2007

SKU: 11868

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*

Make:	Leadwell
Model:	MV-50i
Year:	2007

Features:
Fanuc 18i-MB CNC Control
CAT40 Taper Spindle
24-Station Automatic Tool Changer
Through-Spindle Coolant
Chip Conveyor
12,000 RPM High-Speed Spindle
Operator Manuals

Capacity:
Table Size: 55.8″ L × 23.9″ W

Travels:
X-Axis Travel: 49.9″
Y-Axis Travel: 24.9″
Z-Axis Travel: 19.6″

Spindle:
Spindle Motor: 15 HP
Maximum Spindle Speed: 12,000 RPM
Spindle Taper: CAT40

Automatic Tool Changer:
Tool Changer: Automatic Tool Changer
Tool Capacity: 24 Stations

General:
Machine Weight (Approx.): 14,000–15,000 lb
Machine Dimensions (Approx.): 135″ L × 83″ W × 107″ H

Capacity:
Table Size: 1,417 mm L × 607 mm W

Travels:
X-Axis Travel: 1,267 mm
Y-Axis Travel: 632 mm
Z-Axis Travel: 498 mm

Spindle:
Spindle Motor: 15 HP
Maximum Spindle Speed: 12,000 RPM
Spindle Taper: CAT40

Automatic Tool Changer:
Tool Changer: Automatic Tool Changer
Tool Capacity: 24 Stations

General:
Machine Weight (Approx.): 14,000–15,000 lb
Machine Dimensions (Approx.): 3,429 mm L × 2,108 mm W × 2,718 mm H

Categories	CNC Vertical Machining Centers
Make	Leadwell
Model	MV-50i

Fanuc 18i-MB CNC Control
CAT40 Taper Spindle
24-Station Automatic Tool Changer
Through-Spindle Coolant
Chip Conveyor
12,000 RPM High-Speed Spindle
Operator Manuals

Payment Terms

A booking deposit secures the machine, with the remaining balance due prior to loading or shipment. We accept bank transfer, wire transfer, and approved payment methods.
