*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.*
| Make: | Makino |
| Model: | A66 |
| Year: | 2001 |
| Machine Type: | CNC Horizontal Machining Center |
| CNC Control: | Fanuc 16iM Professional 3 |
| Features: |
|---|
| Fanuc 16iM Professional 3 CNC Control |
| 60-Position Automatic Tool Changer |
| 2-Position Automatic Pallet Changer |
| Full 4th-Axis B-Axis Indexing |
| CAT 40 Spindle |
| Through-Spindle Coolant |
| Chip Conveyor |
| Hydraulic Pallet Clamping |
| Full Enclosure |
| Spindle Chiller |
| Cooling System |
| Coolant Filtration System |
| Capacity: |
|---|
| Pallet Size: 19.7″ × 19.7″ |
| Pallet Capacity: 1,540 lbs. |
| Maximum Workpiece Diameter: 31.5″ |
| Maximum Workpiece Height: 39.4″ |
| Travels: |
|---|
| X-Axis Travel: 31.5″ |
| Y-Axis Travel: 25.2″ |
| Z-Axis Travel: 27.6″ |
| Rapid Traverse: 1,575 IPM |
| Spindle: |
|---|
| Spindle Speed: 14,000 RPM |
| Spindle Power: 35 HP |
| Spindle Taper: CAT 40 |
| Spindle Type: High-Speed |
| Automatic Tool Changer: |
|---|
| ATC Capacity: 60 Positions |
| Tool Taper: CAT 40 |
| Tool Change System: Automatic |
| Pallet Changer: |
|---|
| APC Capacity: 2 Positions |
| Pallet Size: 19.7″ × 19.7″ |
| General: |
|---|
| Cutting Time: 7,605 Hours |
| Machine Weight (Approx.): 25,500 lbs. |
| Machine Dimensions (Approx.): 160″ L × 108″ W × 116″ H |
